PPI Motorcycle - Class-D Amplifier 4 x 100w 4Ω / 4 x 150w 2Ω
ATOM MINI amplifiers adopt the most exemplary Korean Class-D performance, reliability, and this compact footprint fits inside your motorcycle’s fairing. At first glance, you’ll notice several key improvements. All pre-amp & crossover options are conveniently located on one side of this amplifier, while quick-disconnect connection plugs for power and speakers outputs are on the other. You might not notice additions to the circuit board, including improved internal power supply & output stage components. We know you want it loud…
Amplifier bracket & Wiring kit for Harley Davidson® Touring Models found here:
2014+ 98-2013
State-of-the-Art Class D IC Amplifier Technology
2-Ohm Stereo & 4-ohm Bridged Stable Amplifier
Quick Disconnect 8g Power & 14g Speaker Wire Harness
200mV-6V Low-Level RCA Input Harnesses Included
Signal Sensing Turn-On on Hi/Speaker Level Input
Optional Variable 12dB/Octave High-Pass Crossovers
Optional Variable 12dB/Octave Low-Pass / Band-Pass Crossover
Low-Level RCA Output Harness for Daisy Chained Applications
Dimensions: 5.375”W x 1.875”H x 9.25”L
Made In Korea
ATOM MINI Digital Amplifier
| RMS Power 4Ω | 100W x 4 (14.4V, 1KHz, ≤ 1% THD+N) |
| RMS Power 2Ω | 150W x 4 (14.4V, 1KHz, ≤ 1% THD+N) |
| Amplifier Size | 9.25″L x 5.375″W x 1.875″H |
